Smooth surfaces, a fresh, ergonomic design – and an incredibly crystal clear colour display. The menu structure and the artificial intelligence behind it turns high end B type sterilizing into one of the most simple, comfortable and safest systems in the world. For full infection control within your daily work.
So many elements, so much incredible technology and so many parts, completely integrated, in the right place and ready to serve and fulfil the daily requirements of a high end B type sterilizer!
EliSense
LED indicators and display show cycle status information, temperature information and much more to optimize both workflow and output at a glance.
EliTrace
For the first time, the sterilization process can be traced and documented down to the individual instrument or instrument kit. Without additional software or computer.
Eco Dry+
Eco Dry technology adapts the drying time to the mass of the load. This reduces the cycle time, increases the life span of your instruments and optimizes the energy consumption.
Intuitive Interface
The new Lisa crystal clear colour touchscreen not only offers EliSense. It offers the entry to an intelligent menu structure with a wide range of options to make your daily work easier, faster, and more efficient.
Perfect Ergonomics
The revised design is setting optimized hygiene and ergonomic standards in modern dentistry.
New Environmentally Friendly Packaging
The new environmentally friendly packaging is completely reusable and recyclable. Plastic components were reduced to a minimum. For 99% of its weight, the new package is made of cardboard and other fully biodegradable substances.
Extended Documentation
The new Lisa offers the possibility to trace back to the single instrument without any paper handling, dedicated computer or software.
High Capacity Data Logger
The high capacity USB drive automatically records the cycle reports for the entire life of Lisa.
Customized to your Needs
Lisa’s traceability menu offers a wide range of options to customize your own traceability system to your exact needs.
User Identification
Allows you to digitally record the user who loaded and unloaded the sterilizer. Users are identified by a 6-digit PIN.
Load Release Confirmation
This option digitally records the end user name and their confirmation of the successful sterilization and/or test cycle.
Easy and Practical
Lisa enables you to select the number of labels to be printed by LisaSafe either automatically or manually.
Convenient and Economical
The Ethernet connection allows 4 Lisa sterilizers to share one LisaSafe label printer.
W&H Steri App
W&H Steri App is an advanced smartphone and tablet application that allows to control and monitor the status of the autoclaves in your dental clinic. Moreover, the app is able to scan and track dental instruments within a single sterilizing cycle, keeping a related history database on your smart device.
Main features:
Remote control of your sterilizer: the user can remotely command up to 4 sterilizers.
Advanced traceability: EliTrace feature is now fully supported and the App permits to create instrument database directly from your smart device. In addition to this function, the management and tracking of dental instruments is integrated.
Reports creation: the App allows making intervention reports in order to collect data regarding specific treatments.User management: creation and handling of sterilizer users directly from your smart device.
Backup functionality: all the cycle reports are automatically saved to assure more protection of data.
Simple Cycle Selection
As soon as the Lisa is switched on, the home screen immediately displays the cycle selection.
Risk-Free Cycle Selection
The custom cycle selection feature allows you to select which cycles are displayed on the home screen.
User Guidance
Instruction is available with the help button in order to assist you during navigation.
Guided Maintenance
A set of 3-D animations shows you the main maintenance operations step by step. Makes operation easy and straightforward.
Easy Filling
A high capacity integrated funnel prevents water splashes during the water filling process.
Simple Cleaning
Thanks to a smooth surface design with minimized gaps.
High Convenience
An automatic water filling valve allows you to connect a demineralization system. Manual filling and draining are no longer required.
Fits Everywhere
With the modular front feet, Lisa can be installed on the narrowest benches.
Practical Design
Lisa can be built into a cabinet thanks to the optimized internal air circulation.
Effortless Tank Access
The tank cover can be easily removed without tools to clean the tank.
Technical Data:
Chamber size: 17 l / 22 l
Power supply: 200–240 V AC; 50/60 Hz; 10 A
Power consumption: 2.0 - 2.4 kW
Overall dimension(width x height x depth): 465 x 452 x 634 mm
Weight: 46 kg / 47.5 kg
Main / Used water tanks: 4.8/4.8 l
Working range: 7 to 15 cycles
Usable space in chamber(width x height x depth)¹: 195 x 195 x 312 mm / 195 x 195 x 400 mm
Connection types: 1 Ethernet port, 5 USB ports, integrated automatic water filling valve
